Reel Aluminum Inspecting Rewinding Machine

Zontai ZTM-H Series Automatic Doctoring Rewinding Machine

Core Application & Performance Capabilities

The Zontai ZTM-H Series is expertly engineered for inspecting and rewinding printing film, delivering exceptional performance with a maximum working speed of 400m/min. It is widely applied in demanding sectors such as pharmaceutical packaging, flexible food packaging, and high-end label printing. Whether processing standard films, highly reflective aluminum foils, or sensitive stretch films, this machine ensures non-destructive handling and high-precision defect detection at peak operational velocities.

Engineered for maximum versatility, the system accommodates a broad web width ranging from 300-1300mm, making it ideal for diverse production runs. Both the unwinder diameter and rewinder diameter support up to 800mm, allowing for extended continuous operation with large jumbo rolls. Furthermore, the unwinder and rewinder core mechanisms are fully compatible with both 3 inch and 6inch formats, providing operators with the flexibility to seamlessly switch between different material suppliers and roll specifications without prolonged downtime.

To maximize operational flexibility and minimize material waste, the equipment is designed so that it can perform both forwarder and reverse operation. This bidirectional capability empowers operators to instantly backtrack and re-evaluate specific sections of the web if a defect is suspected, ensuring absolute quality control without the need to unload and reload the heavy material rolls.

Comprehensive Defect Detection Systems

For meticulous visual assessment, the workstation is equipped with strobe light/ inpection light for manual checking. This targeted illumination system casts a crisp, consistent light across the moving web, allowing operators to visually perceive subtle print inconsistencies, color shifts, or physical surface blemishes that might otherwise go unnoticed during rapid production runs.

Beyond manual oversight, this rewinder truly excels in automation. It can be seamlessly worked with automatic inspection system, such as AVT, DAC, E+L, Sotry, Kesai, or virtually any brands of inspecting systems available on the global market. By integrating these advanced visual detection networks, the machine achieves 100% defect interception and automatic isolation, ensuring that only flawless, compliant packaging materials proceed to the final delivery stage.

Advanced Drive & Tension Architecture

Handling heavy material rolls is dramatically simplified because both the unwinder and rewinder use shaftless type hydraulic system control. This robust hydraulic infrastructure allows operators to securely lift, engage, and disengage massive rolls directly from the floor with minimal physical exertion, significantly accelerating setup times and enhancing workplace safety during intensive production shifts.

To maintain pristine web geometry, the material's up and down adopts separate motor and speed reducer, this type will make press roller always keep same angle in the material, regardless of the roll's changing diameter as it processes. This constant geometry is critical for preventing air entrapment and ensuring a perfectly tight, uniform finish.

Because of this independent motorization and precise angle management, the overall web tension will be more stable than normal type of rewinding machinery. This extreme tension stability is paramount when running delicate stretch films or rigid aluminum foils at 400m/min, completely eliminating the risk of material elongation, wrinkling, or lateral shifting during rapid acceleration and deceleration phases.

Workflow Optimization & Precision Alignment

To facilitate continuous, uninterrupted processing, the machine features an integrated joint table for connecting rolls in unwinder and rewinder sides. This ergonomically positioned splicing station provides a flat, secure surface equipped with pneumatic clamps, enabling operators to execute clean, perfectly aligned splices rapidly, thereby maintaining web integrity across multiple roll changes.

Finally, to guarantee the structural perfection of the finished roll, the system integrates a good brand LPC for correct the deviation. This highly responsive edge-guiding technology continuously monitors the web path and makes micro-adjustments in real-time, ensuring that the final rewound roll features a flawlessly straight edge, ready for immediate deployment in subsequent packaging or converting processes.

Industry Compliance & Global Support

Committed to excellence in the global packaging sector, the Zontai ZTM-H Series is manufactured in strict accordance with international regulatory standards, ensuring long-term reliability and safety.

• Regulatory Certifications: Fully compliant with CE and ISO9001 standards, fulfilling the stringent hygiene and operational compliance requirements mandated by pharmaceutical and food-grade packaging authorities.

• Global Technical Assistance: We provide a comprehensive worldwide support network, offering rapid equipment delivery, exhaustive on-site installation, and hands-on operator training to ensure seamless integration into your facility.

• Lifecycle Maintenance: Our dedicated after-sales framework guarantees that your production lines maintain peak productivity with minimal downtime, supported by experts ready to assist with system upgrades and troubleshooting.

Main Technical Parameters
